Item # 53693N08050
M 8-1.25 x 50 Hex Flange Bolt Large O.D., Class 10.9 Black Zinc with Patch. IFI 536 / ISO 4162
- UM: C
- Weight: 0.0577
- Brand: PATCH SCREWS
- PARTIAL THREAD
- IFI 536 , ISO 4162 Hex Head Flange Bolt Small Series have a flange under the bolt head that acts like a washer to distribute the load. Flange bolts that are usually non-serrated are sometimes called frame bolts.
Similar to ISO 10501
Specifications
| Diameter | M 8 |
| Thread Pitch | 1.25 |
| Length | 50mm |
| Head Wd. | 10mm |
| Head Ht. | 8.5mm |
| Flange Dia. | 17mm |
| Thread Len. | 22mm |
×
